Alcatel OmniPCX Office Technical Documentation

File
3
EXAMPLES USING ARSCALL SERVER : PRIVATE NETWORKS
Ed. 04 3/16Réf. 3EH 21000 BSAA
CONVERSION BETWEEN PUBLIC AND PRIVATE NUMBERING PLANS
Case 1: Peer to peer - ISVPN and overflow
This configuration corresponds to a call in an ISVPN heterogeneous network or an overflow on a public
link when the private QSIG-BC link is busy.
ARS table of for overflow mechanism
Network Prefix Ranges Substitute TrGp list Called/HH User com.
Pub 32 -
00 - 99
32
03886777
1
0
Heterogen.
Heterogen.
PUBLIC
NETWORK
0
0
1
1
0384273045
QSIG_BC
B
A
DDI : 0388697901
3101
DDI : 0388677710
3210
A
PUBLIC
NETWORK
0
0
1
1
0384273045
A
B
DDI : 0388697901
3101
DDI : 0388677710
3210

Alcatel OmniPCX Office Specifications

General

VoIP Support	Yes
SIP Support	Yes
ISDN Support	Yes
Analog Support	Yes
Integrated Voice Mail	Yes
Auto Attendant	Yes
Conferencing	Yes
VoIP Protocols	SIP, H.323
Power Supply	100-240 VAC, 50/60 Hz
Network Interfaces	10/100 Mbps Ethernet
Humidity	10% to 90% non-condensing
