EXAMPLES USING ARSCALL SERVER : PRIVATE NETWORKS
Ed. 04 11/16Réf. 3EH 21000 BSAA
To make a call from 0388408124 on PABX arrive at set 836 on PABX (after someone has mo-
ved to new office, for example).
Settings:
Modification of the public numbering plan of PABX :
In the ARS table of PABX , add:
Call description:
- (14): the range of DDI numbers is modified in order to retrieve a number.
- (15): an incoming call for user 0388408124 is analyzed by the public numbering plan as an ARS
call with conservation of the prefix.
- (16): the number arriving in the ARS table is changed to 836 then sent on trunk group list 1.
Nota : Identification of a public call as a private call.
In the event of overflow, during a call on the QSIG link from to , the display on a set belonging
to states the internal number of the user of (for example: 121 calls 835; the display on set 835
states "121 calling").
On the other hand, if the call is sent via the T0 accesses (if QSIG and ATL busy), the display states the
public number (in the example, the display on set 835 states "0388408121 calling").
Start End Base Function NMT Private
8120 8123 120 Set - No (14)
8124 8124 ARS Secondary trunk group Keep No (15)
Network Prefix Ranges Substitute TrGp list Called/HH User com.
Public 0388408124 - 836 1 Heterogen. (16)
B A
B
B
B A
A B
