CALL METERING SERVICES APPLICATIONS
Ed. 042/30 Réf. 3EH 21000 BSAA
Connection
15 m max.
V24
UAI
RD
TD
0V
3
2
7
4
5
RTS
CTS
15 m max.
V24
RD
TD
0V
3
2
5
7
8
RTS
CTS
UAI
Printer or external
management system
Metering
printer
Option 4083ASM
Connector
SUBD 25 pins
If the printer does not manage the
RTS/CTS signals, strap 4-5.
Alcatel
OmniPCX
Office
Printer or external
management system
Metering
printer
Option 4093 ASY-CTI
Connector
SUBD 9 pins
If the printer does not manage the
RTS/CTS signals, strap 7
-
8.
