BRA BOARD HARDWARE
Ed. 042/2 Réf. 3EH 21000 BSAA
OUTPUT PORTS (BOARD STIFFENER)
CONNECTING A T0 ACCESS
The Alcatel OmniPCX system can be installed near the digital network termination or at a certain dis-
tance (up to 350 m), as required.
RJ45 pin 12345678
Outputs TX+ RX+ RX- TX-
12 34
5
6
7
8
ISDN ACESS - T0
BRA8
12345678
Female RJ45
,
front
Distribution panel
ISDN ACCESS - T0
DNT
Transmission
Reception
TX
RX
BRA8
