Rockwell Automation Publication 2198-UM001I-EN-P - May 2019 33
Plan the Kinetix 5500 Drive System Installation Chapter 2
AC Line Filter Selection
An AC line filter is required to meet CE requirements. Install an AC line filter
for input power as close to the 2198-Hxxx-ERSx drive as possible.
Table 7 - AC Line Filter Selection
Table 8 - AC Line Filter Selection for Shared AC and Shared AC/DC and Hybrid Multi-axis Systems
IMPORTANT AC line filters are only recommended with grounded WYE power
configurations. For facility power configuration examples, see Determine the
Input Power Configuration on page 75.
Kinetix Drive Module
Cat. No.
AC Line Filter
Cat. No.
2198-H003-ERSx
2198-H008-ERSx
2198-H015-ERSx
2198-DB08-F
2198-H025-ERSx
2198-H040-ERSx
• 2198-DBR20-F or
• 2198-DB20-F
2198-H070-ERSx
• 2198-DBR40-F or
• 2198-DB42-F
IMPORTANT Use 2198-DBxx-F line filters only as field replacements in existing
installations. Select 2198-DBRxx-F line filters for all new systems or to
replace existing 2198-DBxx-F line filters. This does not apply to
2198-DB08-F line filters.
Kinetix 5500 Drives
Cat. No.
Drive Voltage,
(three-phase)
nom
AC Line Filter Cat. No.
2
Axes
3
Axes
4
Axes
5
Axes
6
Axes
7
Axes
8
Axes
2198-H003-ERSx 240/480V 2198-DBR20-F
2198-H008-ERSx 240/480V 2198-DBR20-F
2198-H015-ERSx 240/480V 2198-DBR20-F –
2198-H025-ERSx 240/480V 2198-DBR40-F –
2198-H040-ERSx 240/480V 2198-DBR40-F 2198-DBR90-F –
2198-H070-ERSx 240/480V 2198-DBR90-F –
