Rockwell Automation Publication 2198-UM001I-EN-P - May 2019 211

Upgrade the Drive Firmware Appendix B

Upgrade Firmware

Follow these steps to select the drive module to upgrade.

1. In the Logix Designer application, from the Tools menu, choose

ControlFLASH.

The Welcome to ControlFLASH dialog box appears.

2. Click Next.

The Catalog Number dialog box appears.

TIP You can also open ControlFLASH software by choosing

Start>Programs>FLASH Programming Tools>ControlFLASH.
