Rockwell Automation Publication 2198-UM001I-EN-P - May 2019 83
Connect the Kinetix 5500 Drive System Chapter 5
Wiring Guidelines
Use these guidelines as a reference when wiring the power connectors on your
Kinetix 5500 drive.
Follow these steps when wiring the connectors for your Kinetix 5500 drive.
1. Prepare the wires for attachment to each connector plug by removing
insulation equal to the recommended strip length.
2. Route the cable/wires to your Kinetix 5500 drive.
3. Insert wires into connector plugs.
Refer to connector pinout tables in Chapter 4 or the interconnect
diagrams in Appendix A
.
4. Tighten the connector screws.
5. Gently pull on each wire to make sure it does not come out of its
terminal; reinsert and tighten any loose wires.
6. Insert the connector plug into the drive connector.
ATTENTION: To avoid personal injury and/or equipment damage, observe
the following:
• Make sure installation complies with specifications regarding wire types,
conductor sizes, branch circuit protection, and disconnect devices. The
National Electrical Code (NEC) and local codes outline provisions for safely
installing electrical equipment.
• Use motor power connectors for connection purposes only. Do not use them
to turn the unit on and off.
• Ground shielded power cables to prevent potentially high voltages on the
shield.
IMPORTANT For connector locations of the Kinetix 5500 drives, refer to Kinetix 5500
Connector Data on page 62.
When removing insulation from wires and tightening screws to secure the
wires, refer to the table on page 82
for strip lengths and torque values.
IMPORTANT To improve system performance, run wires and cables in the wireways as
established in Establishing Noise Zones
on page 44.
IMPORTANT Use caution not to nick, cut, or otherwise damage strands as you
remove the insulation.
