46 Rockwell Automation Publication 2198-UM001I-EN-P - May 2019
Chapter 2 Plan the Kinetix 5500 Drive System Installation
Noise Reduction Guidelines for Drive Accessories
Refer to this section when mounting an AC (EMC) line filter or external
passive-shunt resistor for guidelines designed to reduce system failures caused
by excessive electrical noise.
AC Line Filters
Observe these guidelines when mounting your AC (EMC) line filter (refer to
the figure on page 44
for an example):
• Mount the AC line filter on the same panel as the Kinetix 5500 drive
and as close to the drive as possible.
• Good HF bonding to the panel is critical. For painted panels, refer to
the examples on page 42
.
• Segregate input and output wiring as far as possible.
IMPORTANT CE test certification applies to only the AC line filter used with a single drive
or the line filter used in multi-axis drive configurations. Sharing a line filter
with more than one multi-axis drive configuration can perform
satisfactorily, but the customer takes legal responsibility.
