96 Rockwell Automation Publication 2198-UM001I-EN-P - May 2019
Chapter 5 Connect the Kinetix 5500 Drive System
Maximum Cable Lengths
Combined motor cable length for all axes on the same DC bus must not
exceed 250 m (820 ft). The maximum drive-to-motor cable length for
Kinetix 5500 drives and motor/actuator combinations with 2090-CxxM7DF
cables is 20 m (65.6 ft); however, you can replace the existing motor power/
brake cable with a 2090-CSBM1DF or 2090-CSBM1DG single motor cable
to extend the length up to 50 m (164 ft).
Motor Power/Brake Cable Preparation
2090-CPBM7DF (series B) cables are available with 12 and 10 AWG motor-
power conductor sizes. So, 14 AWG cables used on frame 3 drives, which are
physically taller, require preparation.
Cable Preparation for Frame 1 and Frame 2 Drives
For frame 1 and frame 2 drives, the 2090-CPBM7DF (16 and 14 AWG) power
conductor length, 102 mm (4.0 in.), is sufficiently long to reach the MP
connector plug and provide adequate stress relief.
The brake conductor length, 635 mm (25 in.), is much longer than necessary.
We recommend that you measure 163 mm (6.4 in.) from the edge of the cable
jacket (that is covered by heat shrink) and trim off the rest.
Refer to Figure 56
and on page 99 for a typical installation example. For strip
lengths and torque values, refer to Table 40
on page 89.
Cable Preparation for Frame 3 Drives
2090-CPBM7DF (series B) 12 and 10 AWG cables are designed for use with
Kinetix 5500 drives and do not require any modifications.
For frame 3 drives, 2090-CPBM7DF (14 AWG) cables, and 12 and 10 AWG
(series A) cables, the overall length of the cable preparation area needs to be
increased for the motor power conductors to reach the MP connector and also
provide a proper service loop.
IMPORTANT The option to replace 2090-CPBM7DF power/brake cables with
2090-CSBM1DF/DG single cables applies to only 18 and 14 AWG single
cables. 2090-CSxM1Dx-10Axxx (10 AWG/M40 connector) single cables are
not compatible with 2090-CPBM7DF-10Axxx (10 AWG/M40 connector)
power/brake cables.
When replacing your existing motor power/brake cable with a
2090-CSBM1DF/DG single motor cable, only the motor power and brake
conductors are used. Cut off the feedback conductors in the single motor
cable and reuse the existing 2090-Series feedback cable.
