Page #94 background imageLoading...
Page #94 background image
94 Rockwell Automation Publication 2198-UM001I-EN-P - May 2019
Chapter 5 Connect the Kinetix 5500 Drive System
Motor Power and Brake Connections
The motors and actuators in Tab le 44 have separate power/brake and feedback
cables. The motor power/brake cable attaches to the cable clamp on the drive
and the power/brake conductors attach to the MP and BC connectors,
respectively.
Table 44 - Current Motor Power Cable Compatibility
Refer to Motor Power Connections on page 88 and Motor Brake Connections
on page 89
for the MP and BC connector specifications.
Table 45 - Legacy Motor Power Cables
Table 46 - Induction Motor Power Cable Specifications
Motor/Actuator Cat. No.
(1)
(1) The 2198-H2DCK (series B or later) feedback converter kit is required.
Motor Power Cat. No.
(2)
(with brake wires)
(2) Refer to the Kinetix Motion Accessories Specifications Technical Data, publication KNX-TD004, for cable specifications.
Motor Power Cat. No.
(2)
(without brake wires)
MPL-A/B15xxx-xx7xAA, MPL-A/B2xxx-xx7xAA,
MPL-A/B3xxx-xx7xAA, MPL-A/B4xxx-xx7xAA,
MPL-A/B45xxx-xx7xAA, MPL-A/B5xxx-xx7xAA,
MPL-B6xxx-xx7xAA
2090-CPBM7DF-xxAAxx
(standard) or
2090-CPBM7DF-xxAFxx
(continuous-flex)
2090-CPWM7DF-xxAAxx
(standard) or
2090-CPWM7DF-xxAFxx
(continuous-flex)
MPM-A/Bxxxx, MPF-A/Bxxxx, MPS-A/Bxxxx
MPAS-A/Bxxxx1-V05SxA, MPAS-A/Bxxxx2-V20SxA
MPAI-A/Bxxxx, MPAR-A/B3xxx,
MPAR-A/B1xxx and MPAR-A/B2xxx (series B)
LDAT-Sxxxxxx-xDx N/A
Motor Cable Description Motor Power Cat. No.
Standard
Power/brake, threaded 2090-XXNPMF-xxSxx
Power-only, bayonet 2090-XXNPMP-xxSxx
Continuous-flex
Power/brake, threaded 2090-CPBM4DF-xxAFxx
Power-only, threaded 2090-CPWM4DF-xxAFxx
Power-only, bayonet 2090-XXTPMP-xxSxx
Cable Manufacturer Cable Series Voltage Rating Temperature Rating
Belden 29500-29507
600V 90 °C (194 °F)Lapp Group ÖLFEX VFD XL
SAB VFD XLPE TR
