Rockwell Automation Publication 2198-UM001I-EN-P - May 2019 81

Connect the Kinetix 5500 Drive System Chapter 5

Ground Multiple Subpanels

In this figure, the chassis ground is extended to multiple subpanels.

Figure 44 - Subpanels Connected to a Single Ground Point

High-frequency (HF) bonding is not illustrated. For HF bonding information,

refer to Bonding Multiple Subpanels

on page 43.

Follow NEC and applicable

local codes.

Bonded Ground Bus

Ground Grid or Power

Distribution Ground
