Chapter 7 Performance Test
7-24
7.3.1 Required equipment
The following table shows the equipment required for the performance
test.
Before starting performance tests, warm up the MP2110A and measuring
instruments for at least 1 hour.
Table 7.3.1-1 Equipment for Performance Test
Product Name Required Performance
Recommended
Equipment
Pulse Pattern
Generator or
Signal Generator
Clock frequency: 7 GHz
Amplitude: 0.5 Vp-p
MP2110A
(Anritsu)
DC Power Source*
1
Power voltage: ±2.5 V
Power current: ±50 mA
Setting accuracy: 1% or less
With current limiting function
2400
(Keithley
Instruments)
Light Source*
2
Wavelength: 850, 1310, 1550 nm
Output level range: +3 dBm or more
Level stability: ±0.05 dB
Optical Power
Meter*
2
Wavelength: 750 to 1700 nm
Level range: –40 to +10 dBm
(100 nW to 10 mW)
Accuracy: 5%
Linearity ±0.05 dB or less
8163B+81623B
(Keysight
Technologies)
Programmable
Optical
Attenuator*
2,
*
4
For single-mode fiber:
Wavelength: 1200 to 1600 nm
Insertion loss: 3 dB or less
Attenuation: 0 to 30 dB
Resolution: 0.1 dB or less
For multi-mode fiber:
Wavelength: 800 to 900 nm
Insertion loss: 3 dB or less
Attenuation: 0 to 30 dB
Resolution: 0.1 dB or less
G0350F
(Anritsu)
G0351F
(Anritsu)
Fixed Attenuator*
3
20 dB K connector
Bandwidth: DC to 40 GHz
41KC-20
(Anritsu)
Light Source*
4
Wavelength: 1310 nm
Optical fiber: Single mode
Optical Modulation Amplitude (OMA):
0.64 mW (–2 dBm) or more
Bit rate: 25.78125 Gbit/s
MT1000A,
MU100011A,
G0389A
(Anritsu)
Sampling
oscilloscope*
4
Optical interface
Bandwidth: 30 GHz or more
MP2110A
(Anritsu)
*1: Required for MP2110A-021, MP2110A-023, MP2110A-033, and
MP2110A-043
*2: Required for MP2110A-022, MP2110A-023, MP2110A-025,
MP2110A-026, MP2110A-030, MP2110A-032, MP2110A-033,
