Chapter 7 Performance Test
7-30
7.3.3 Optical Power Meter
(1) Specification
Accuracy: ±0.35 dB if the input level is –12 dBm or greater
(2) Setup
Figure 7.3.3-1 Optical Power Meter Test Connection Diagram
(SMF, When using a PPG of MP2110A)
Optical Fiber
Optical Power Meter
Light Source
Programmable
Optical Attenuator
