7.2 Performance Test for Error Detector
7-17
7
Performance Test
7.2.3 Rx sensitivity
(1) Specification
40 mVp-p
BER 10
–12
or less under the following conditions:
Bit rate: 25.78125 Gbit/s
Pattern: PRBS31
Mark ratio: 50%
Single-end
Back-to-back connection
(2) Setup
Same as Figure 7.2.2-1 and Figure 7.2.2-2.
(3) Procedure
1. Connect the
Clk Out
connector and the
Trigger Clk In
connector
of the sampling oscilloscope using a coaxial cable.
2. Connect the coaxial terminators to the
PPG1
Data
Out
and
ED1
Data
In
connectors.
3. Attach a 20 dB fixed attenuator to the
PPG1 Data Out
connector.
(Refer to (a) in Figure 7.2.2-1.)
4. Connect the 20 dB fixed attenuator and
Ch A In
connector using
a coaxial cable.
5. Click PPG/ED Ch1. Configure the settings as shown below:
Item Setting Value
Reference Clock Internal
Symbol Rate 100GbE/4 (25.78125G), 0 ppm
Clock Output Ch1/2
PPG Amplitude 0.4
External ATT 0
Test Pattern (PPG) PRBS 2^31–1, POS
Test Pattern (ED) PRBS 2^31–1, POS
ED Input Condition Single-Ended Data
Threshold 0 mV
PPG Data/XData ON
Gating Cycle Single
Gating Period 45 s
