Appendix A Specifications
A-2
A.1 Configuration
Table A.1-1 Standard Configuration
Model/Ordering No. Product Name Q’ty
– Main unit –
MP2110A
BERTWave
1
– Standard Accessories –
Power Code
1
J0617B
Replaceable optical connector (FC-PC)
*
1
J1632A
TERMINATOR
*
1
J1341A
OPEN
*
1
J1627A
GND connection cable
1
J1763A
U Link Coaxial Cable (K)
1*
2
J1764A
U Link Coaxial Cable (SMA)
1*
2
Z0397A
FC Adaptor Cap
*
1
Z1364A
MX210000A BERTWave Control Software CD-ROM
1
*1: Quantity depends on the options. Refer to Table A.1-2 to Table A.1-4.
*2: Only when MP2100A-054 is added
Table A.1-2 Connection Destination and Quantity of J0617B and Z0397A
Option Number Connection Destination Q’ty
MP2110A-022,
MP2110A-032,
MP2110A-042
Ch A In SMF, Ch A In MMF,
Ch B In SMF, Ch B In MMF
4
MP2110A-023,
MP2110A-033,
MP2110A-043
Ch B In SMF, Ch B In MMF
2
MP2110A-025,
MP2110A-035,
MP2110A-045
Ch B In SMF
1
MP2110A-026,
MP2110A-036,
MP2110A-046
Ch B In MMF
1
MP2110A-030,
MP2110A-040
Optical In SMF
Ch A, Ch B, Ch C, Ch D
4
MP2110A-039,
MP2110A-049
Optical In MMF
Ch A, Ch B, Ch C, Ch D
4
MP2110A-055
Optical SMF
Data In, Data Out
2
