A.3 Sampling Oscilloscope
A-23
Appendix A
A.3.9 Electrical Channel
Table A.3.9-1 Electrical Channel Function
Item Specifications
Amplitude Setting
Scale
Scale Setting on the vertical axis. Both ChA and ChB can be set as follows
1 to 200 mV/div, 0.1 mV step
Offset
Offset setting on the vertical axis. Both ChA and ChB can be set as follows
–500 to 500 mV, 1 mV step
Attenuation
Function of correcting Amplitude Scale / Offset and measurement result in
conjunction with the input attenuation of the attenuator connected to Data
Input
0.00 to 30.00 dB, 0.01 dB step
Tracking*
Function to make the other channel track the active channel’s Scale, Offset
and Attenuation values.
ON/OFF
Channel Math*
Function to draw calculation results of ChA and ChB
Channel Math
Enable
ON/OFF
Define Function
Selects the calculation method
ChA + ChB
ChA – ChB
ChB – ChA
Scale
Sets scale in Vertical Axis at displaying Channel Math calculation
1 to 200 mV/div, 0.1 mV step
Offset
Sets offset in Vertical Axis at displaying Channel Math calculation
–1000 to 1000 mV, 0.1 mV step
*: Available when MP2110A-x21 is installed.
