Appendix A Specifications
A-22
A.3.7 Horizontal System
Table A.3.7-1 Horizontal System
Item Specifications
Trigger Clk In
Connector
SMA Connector (f.)
Termination
50
Ω
, AC coupled
Trigger Clock
Frequency
0.1 to 15.0 GHz
When this item is set in the range of 2.4 to 15.0 GHz, the Precision Trigger
function can be set to ON.
Trigger Clock
Sensitivity
Typical 100 mVp-p, Max. 200 mVp-p*
1
Typical 200 mVp-p*
2
Maximum
Amplitude
Min. 1.2 Vp-p
Maximum
Amplitude
(Before Damage)
2 Vp-p
Jitter, RMS
1.25 GHz or more, 15 GHz or less:
Typical 0.4 ps, Max. 1.35 ps
0.1 GHz or more, less than 1.25 GHz:
Typical 1.0 ps, Max. 1.5 ps
2.4 GHz or more, 15 GHz or less and when Precision Trigger is ON:
Typical 200 fs*
3,
*
4
, Max. 280 fs*
3
When MP2110A-030, 039, 040 or 049 is installed
1.25 GHz or more, 15 GHz or less:
Typical 350 fs, Max. 600 fs
0.1 GHz or more, less than 1.25 GHz:
Typical 1.0 ps, Max. 1.5 ps
*1: It is specified by inputting the square wave when the trigger clock
frequency is 1 GHz or less.
*2: When Precision Trigger is ON.
*3: Evaluation by connecting the sine wave output of the MG3695A or
equivalent to the Trigger input.
*4: At 25±5ºC
A.3.8 Digital System
Table A.3.8-1 Digital System
Item Specifications
Sampling Speed
150 kSamples/s, Nominal
Effective Sampling
Speed
250 kSamples/s, Nominal
With Number of Sample = 1350, Symbol Rate = 25.78125 Gbaud,
Clock Rate = 6.4453125 GHz, Eye Mode, UI on Screen = 2 UI
Process Speed
Effective process speed of Reference Equalizer
Nominal 130 ksps @ 26.5625 Gbaud, Test Pattern = SSPRQ
When setting Coherent Eye
