4.1 Window Configuration
Figure 4.1-1 shows the names of elements in the application window and
their layout.
Figure 4.1-1 Names of Application Window Elements
The elements that are set as common in the channels other than Ch 1 are
displayed by light blue characters.
System
Menu
All Measurements
Stop
All
St
art
All Channels
Output off
Status
Indicator
Date and
Time
Function Menu
Measurement
Display Area
All Channels
Outpu
t on
Channel
Tracking
All Channels
BER Results
Version
