A.2 BERT
A-7
Appendix A
A.2 BERT
A.2.1 Common Performances
Table A.2.1-1 Common Functions and Performances
Item Specifications
Internal clock
Frequency
10 MHz
Accuracy
±10 ppm*
1
Bit rate offset
±100 ppm*
2
Ext Clk In
Function to input an external synchronous clock.
Frequency
Without MP2110A-093 With MP2110A-093
607.5 MHz – 100 ppm to
705.0 MHz + 100 ppm
593.75 MHz – 100 ppm to
887.5 MHz + 100 ppm*
3
607.5 MHz – 100 ppm to
705.0 MHz + 100 ppm*
4
Connector
SMA, female
Termination
50
Ω
, AC coupled
Amplitude
0.2 to 1.6 Vp-p
Waveform
Square or sine wave
Division ratio
Without MP2110A-093 With MP2110A-093
1/40
1/16*
3
1/40*
4
Sync Output
Output Signal Type
1/8, 1/16, 1/40, Pattern Sync
Output Level
High Level (V
OH
): –0.2 to 0.05 V
Low Level (V
OL
): –1.2 to –0.7 V
Connector
SMA, female
*1: 1 hour after power-on
*2: The offset can adjust only when using the internal clock. (Common
setting in all channels)
*3: When operation bit rate is set in the range of 9.5 to 14.2 Gbit/s.
*4: When operation bit rate is set in the range of 24.3 to 28.2 Gbit/s.
