Appendix A Specifications
A-12
A.3 Sampling Oscilloscope
A.3.1 Channel Configuration
Table A.3.1-1 Channel Configuration
Option Number Ch A Ch B Ch C Ch D
MP2110A-x21
Electrical channel
Electrical channel
None
None
MP2110A-x22,
MP2110A-x32,
MP2110A-x42
Optical channel
Optical channel
None
None
MP2110A-x23,
MP2110A-x33,
MP2110A-x43
Electrical channel
Optical channel
None
None
MP2110A-x25,
MP2110A-x35,
MP2110A-x45
None
SMF Input
Optical channel *
1
None
None
MP2110A-x26,
MP2110A-x36,
MP2110A-x46
None
MMF Input
Optical channel *
2
None
None
MP2110A-x30,
MP2110A-x40
SMF Input
Optical channel*
1
SMF Input
Optical channel*
1
SMF Input
Optical channel*
1
SMF Input
Optical channel*
1
MP2110A-x39,
MP2110A-x49
MMF Input
Optical channel*
2
MMF Input
Optical channel*
2
MMF Input
Optical channel*
2
MMF Input
Optical channel*
2
*1: No MMF Input
*2: No SMF Input
A.3.2 Common Performances
Table A.3.2-1 Common Functions and Performances
Item Specifications
Sampling System
Sampling Mode
Eye, Pulse, Coherent Eye, Advanced Jitter*
1
Test Pattern*
2
Without MP2110A-095
With MP2110A-095*
3
Variable
Variable, PRBS2^7-1 (127 symbols)*
4
,
PRBS2^9-1 (511 symbols)*
4
, PRBS2^11-1 (2047
symbols)*
4
, PRBS2^13-1 (8191 symbols)*
4
,
PRBS2^15-1 (32767 symbols)*
4
, SSPRQ (65535
symbols)*
4
*1: Available when MP2110A-096 is installed
*2: Trigger division ratio operates at 1, 2, 4, 8, 16, 32, 40, 48 or 64
*3: Possible to analyze the following patterns with Pulse/Coherent Eye
(Impossible to analyze with Variable)
PRBS2^7-1 (127 symbols), PRBS2^9-1 (511 symbols), PRBS2^11-1
(2047 symbols), PRBS2^13-1 (8191 symbols), PRBS2^15-1 (32767
symbols), SSPRQ (65535 symbols)
