A.3 Sampling Oscilloscope
A-13
Appendix A
*4: Operation is guaranteed at Symbol Rate of 9.95 Gbaud to 40 Gbaud.
Possible to analyze when Symbol Length is same
Table A.3.2-1 Common Functions and Performances (Cont’d)
Item Specifications
Number of Samples
Number of samples on one screen
<Eye>: 1350, 2048, 4050
<Pulse, Coherent Eye>: 512, 1024, 2048, 4096, 8192, 16384*
5
Sampling
Run: Execute sampling
Hold: Stop sampling
Display
Ch A: ON/OFF, Ch B: ON/OFF, Ch C: ON/OFF, Ch D: ON/OFF
Accumulation Type
Waveform display method
None: Display with no accumulation
Infinite: Display with unlimited accumulation
Limited: Display with accumulation up to the specified sample
number, time, or number of waveforms
Persistency: Display with afterglow indication for the specified time
Averaging: Display by averaging the specified number of waveforms
Averaging can be selected only when Sampling Mode is Pulse
When Sampling Mode is Advanced Jitter, only Infinite, Limited can be
selected
Limit Type
Specifies cumulative completion condition when Accumulation Type is set to
Limited
Time: Measurement stops when the cumulative time exceeds the
set time
Sample: Measurement stops when the total cumulative number of
samples exceeds the set number of samples.
Waveform: Measurement stops when the total waveform sweep count
exceeds the set sweep count.
Pattern*
6
: Measurement stops if the total acquisition pattern count
exceeds the set sweep count.
Clear Display
Clears display drawing
Auto Scale
Sets Time Scale and Amplitude to optimum values automatically
*5: Fixed to 16384 when Coherent Eye and Test Pattern are set
*6: Not available when Sampling Mode is
Eye
