Appendix A Specifications
A-16
A.3.4 Measurement
Table A.3.4-1 Measurement
Item Specifications
Signal Type Specifies the signal type of the target channel
NRZ, PAM4*
Active Channel Selects one channel among Ch A, Ch B, Ch C and Ch D.
Marker X1: ON/OFF, X2: ON/OFF
Y1: ON/OFF, Y2: ON/OFF
*: PAM4 is selectable when MP2110A-095 is installed
Table A.3.4-2 Amplitude/Time Measurement
Item Specifications
Measurement Select For channels with Signal Type set to NRZ, the following items can be
measured
One Level, Zero Level, Eye Amplitude, Eye Height, Eye Height (Ratio)*
2
,
Crossing, SNR, Average Power (dBm)*
1
, Average Power (mW)*
1
,
Extinction Ratio*
1
, Jitter p-p, Jitter RMS, Rise Time, Fall Time, Eye
Width, DCD, OMA (dBm)*
1
, OMA (mW)*
1
, VECP*
1,
*
3
,
OMA at Crossing*
1,
*
3
, TDEC*
2
, RIN OMA*
1,
*
4
For channels with Signal Type set to PAM4, the following items can be
measured
TDECQ*
1
, Outer OMA (dBm)*
1,
*
5
, Outer OMA (µW)*
1
, Outer ExR*
1
,
Linearity, Ceq*
1,
*
4
, Pertial TDECQ*
1,
*
4
,
Levels (Level 3, Level 2, Level 1, Level 0) ,
Levels RMS (Level 3, Level 2, Level 1, Level 0) ,
Levels P-P (Level 3, Level 2, Level 1, Level 0) ,
Level Skews (Level 3, Level 2, Level 1, Level 0),
Eye Levels (Upper, Middle, Lower), Eye Skews (Upper, Middle, Lower),
Eye Heights (Upper, Middle, Lower), Eye Widths (Upper, Middle, Lower),
Average Power (dBm)*
1
, Average Power (mW)*
1
, RINOMA*
1,
*
4
,
Transition Time (Rise/Fall)*
1,
*
6
, Transition Time (Slow)*
1,
*
6
,
Over/Under-shoot*
1,
*
6
, P-P Power*
1,
*
6
When MP2110A-096 is installed on the channel whose Signal Type is NRZ,
the following items can be measured *
7
TJ (User Define)*
8
, RJ (d-d) , DJ (d-d) , J2 Jitter, J4 Jitter*
2
, J9 Jitter,
Eye Opening*
8
, RJ (rms) PJ (p-p), DDJ (p-p), DCD, ISI (p-p), DDPWS,
PJ Frequency*
9
*1: When optical input channel is selected
*2: Supported with Version 7 or later
*3: Supported with Version 6 or later
*4: Supported with Version 7.00.13 or later
*5: Supported with Version 7.01.18 or later
*6: Supported with Version 7.02.10 or later
