7.3 Performance Test for Sampling Oscilloscope
7-41
7
Performance Test
7.3.5 26G/53G CRU (MP2110A-055)
(1) Specification
Sensitivity: 265 µW or less (OMA)
25.78125 Gbit/s, PRBS2
31
–1 NRZ, Wavelength 1310 nm
(2) Setup
Figure 7.3.5-1 CRU Sensitivity Test Connection Diagram (Amplitude Check)
Figure 7.3.5-2 MT1000A Settings
Optical Fiber
Programmable
Optical Attenuator
Light Source
(SFP28)
