A.1 Configuration
A-3
Appendix A
Table A.1-3 Connection Destination and Quantity of J1632A
Option Number Connection Destination Q’ty
MP2110A-011
Data Out×1,
Data
Out×1,
Sync
Out×1
3
MP2110A-012
Data Out×2,
Data
Out×2,
Sync
Out×1
5
MP2110A-014
Data Out×4,
Data
Out×4,
Sync
Out×1
9
MP2110A-054
O/E Monitor Out×1
1*
*: When MP2110A-022, MP2110A-023, MP2110A-025, MP2110A-026,
MP2110A-030, MP2110A-032, MP2110A-033, MP2110A-035,
MP2110A-036, MP2110A-039, MP2110A-040, MP2110A-042,
MP2110A-043, MP2110A-045, MP2110A-046, or MP2110A-049 is
added.
Table A.1-4 Connection Destination and Quantity of J1341A
Option Number Connection Destination Q’ty
MP2110A-011
Ext Clk In, Clk Out, Sync Out×1, Data In×1,
Data
In×1
5
MP2110A-012
Ext Clk In, Clk Out, Sync Out×1, Data In×2,
Data
In×2
7
MP2110A-014
Ext Clk In, Clk Out, Sync Out×1, Data In×4,
Data
In×4
11
MP2110A-021
Trigger Clk In, Ch A In, Ch B In
3
MP2110A-022,
MP2110A-032,
MP2110A-042
Trigger Clk In
1
MP2110A-023,
MP2110A-033,
MP2110A-043
Trigger Clk In, Ch A In
2
MP2110A-025,
MP2110A-035,
MP2110A-045
Trigger Clk In
1
MP2110A-026,
MP2110A-036,
MP2110A-046
Trigger Clk In
1
MP2110A-030,
MP2110A-039,
MP2110A-040,
MP2110A-049
Trigger Clk In
1
MP2110A-054
CRU In×1, CRU Out×1
2
MP2110A-055
Recovered Clock Out×1
1
