Chapter 7 Performance Test
7-14
Figure 7.2.2-2 ED1
Data In Input Sensitivity Test Connection Diagram
Coaxial Terminator
Fixed Attenuator
Coaxial Terminator
Fixed Attenuator
(a) Amplitude Check
(b) Input Level Measurement
