7.3 Performance Test for Sampling Oscilloscope
7-31
7
Performance Test
Figure 7.3.3-2 Optical Power Meter Test Connection Diagram
(MMF, when using a signal generator)
Optical Fiber
Optical Power Meter
Light Source
Programmable
Optical Attenuator
