Table 1.2.1-2 Connection Destination and Quantity of J0617B and
Z0397A
Option Number Connection Destination Q’ty
MP2110A-030, MP2110A-040 Optical In SMF
A, B, C, D
4
MP2110A-039, MP2110A-049 Optical In MMF
A, B, C, D
4
MP2110A-022, MP2110A-032,
MP2110A-042
Ch A In SMF, Ch A In MMF,
Ch B In SMF, Ch B In MMF
4
MP2110A-023, MP2110A-033,
MP2110A-043
Ch B In SMF, Ch B In MMF 2
MP2110A-025, MP2110A-035,
MP2110A-045
Ch B In SMF 1
MP2110A-026, MP2110A-036,
MP2110A-046
Ch B In MMF 1
MP2110A-055 Optical SMF
Data In, Data Out
2
Table 1.2.1-3 Connection Destination and Quantity of J1632A
Option Number Connection Destination Q’ty
MP2110A-011 Data Out×1,
Data
Out×1,
Sync
Out×1 3
MP2110A-012 Data Out×2,
Data
Out×2,
Sync
Out×1 5
MP2110A-014 Data Out×4,
Data
Out×4,
Sync
Out×1 9
MP2110A-054 O/E Monitor Out ×1 1*
*: When MP2110A-022, MP2110A-023, MP2110A-025, MP2110A-026,
MP2110A-030, MP2110A-032, MP2110A-033, MP2110A-035,
MP2110A-036, MP2110A-039, MP2110A-040, MP2110A-042,
MP2110A-043, MP2110A-045, MP2110A-046, or MP2110A-049 is
installed.
