Appendix B Initial Values
B-2
B.2 PPG/ED
Table B.2-1 Initial Values of PPG/ED
Item Initial Value
Data/XData OFF
Bit Rate Standard Variable
Bit Rate 25781250 kbit/s
Bit Rate Offset 0 ppm
PPG Amplitude 0.40 Vp-p
Ext ATT 0 dB
ED Input Condition Single-Ended Data
Ext ATT 0 dB
Threshold 0 mV
PPG Test Pattern PRBS 2^9–1
PPG Test Pattern Logic POS
ED Test Pattern PRBS 2^9–1
ED Test Pattern Logic POS
ED Test Pattern Tracking ON
ED Result “All”
Result Time Start Time
Reference CLK Internal
Sync Out PPG_1/8Clk
Clk Out Ch1/2
Gating Cycle Repeat
Gating Period 1 S
Current ON
