D.1 Pulse Pattern Generator
D-3
Appendix D
Table D.1-2 Pulse Pattern Generator Performance Test Record Form (Without MP2110A-093)
Frequency Accuracy
Connector
Set Bit Rate
(kbit/s)
Minimum Value
(kHz)
Measured Value
(kHz)
Maximum Value
(kHz)
Pass/Fail
Sync Out
28200000 3524964.8 3525035.2 Pass/Fail
24300000 3037469.7 3037530.3 Pass/Fail
Measurement Channel PPG 1 2 3 4
Waveform (Amplitude)
Connector Set Amplitude Minimum Value Measured Value Maximum Value Pass/Fail
Data Out
0.1 Vp-p 0.06 Vp-p Vp-p 0.14 Vp-p Pass/Fail
0.8 Vp-p 0.62 Vp-p Vp-p 0.98 Vp-p Pass/Fail
Out
0.1 Vp-p 0.06 Vp-p Vp-p 0.14 Vp-p Pass/Fail
0.8 Vp-p 0.62 Vp-p Vp-p 0.98 Vp-p Pass/Fail
Waveform
Connector Item Minimum Value Measured Value Maximum Value Pass/Fail
Data Out
Crossing 40% % 60% Pass/Fail
Rise Time ps 17 ps Pass/Fail
Fall Time ps 17 ps Pass/Fail
Jitter (rms) ps 0.9 ps Pass/Fail
Out
Crossing 40% % 60% Pass/Fail
Rise Time ps 17 ps Pass/Fail
Fall Time ps 17 ps Pass/Fail
Jitter (rms) ps 0.9 ps Pass/Fail
Skew
Connector Set Amplitude Minimum Value Measured Value Maximum Value Pass/Fail
Data Out,
Out
0.3 Vp-p ps ±8 ps Pass/Fail
Data
Data
Data
