D.2 Error Detector
D-7
Appendix D
Table D.2-2 Error Detector Performance Test Record Form (With MP2110A-093)
Measurement Channel ED 1 2 3 4
Operating Frequency
Connector Set Bit Rate
Minimum
Value
ER Measured
Value
Maximum
Value
Pass/Fail
Data Out
28200000 kbit/s 1E–12 Pass/Fail
9500000 kbit/s 1E–12 Pass/Fail
Out
28200000 kbit/s 1E–12 Pass/Fail
9500000 kbit/s 1E–12 Pass/Fail
Rx Sensitivity
Connector Set Bit Rate
Minimum
Value
ER Measured
Value
Maximum
Value
Pass/Fail
Data Out
25781250 kbit/s 1E–12 Pass/Fail
Out
25781250 kbit/s 1E–12 Pass/Fail
Input Level
•
Pattern
Connector Pattern
Minimum
Value
ER Measured
Value
Maximum
Value
Pass/Fail
Data Out
PRBS2^7–1 1E–12 Pass/Fail
PRBS2^9–1 1E–12 Pass/Fail
PRBS2^15–1 1E–12 Pass/Fail
PRBS2^23–1 1E–12 Pass/Fail
PRBS2^31–1 1E–12 Pass/Fail
Out
PRBS2^7–1 1E–12 Pass/Fail
PRBS2^9–1 1E–12 Pass/Fail
PRBS2^15–1 1E–12 Pass/Fail
PRBS2^23–1 1E–12 Pass/Fail
PRBS2^31–1 1E–12 Pass/Fail
Data
Data
Data
