2.1 Unpacking and Installation
2-3
2
CAUTION
• If the MP2110A is not installed in a “good” direction as
above, a small shock may turn it over and harm the
user.
•
Do not stack three or more MP2110As on top of each
other when using them. There is a risk of injury,
because stacked MP2110As are unstable and can fall
due to vibration or shock.
The withstand load of the MP2110A top panel is 10 kg. When placing a
monitor and other equipment on the MP2110A, the total weight of the
placed equipment should not exceed 10 kg. Fix the monitor, etc. on
MP2110A to avoid falling it down from the top panel due to vibration or
shock.
A fan is installed in the MP2110A to prevent the internal temperature
from rising. Install the MP2110A in a location with the vents at least 10
cm away from walls, peripherals or other obstructions so as not to block
the fan perimeter.
Figure 2.1.2-2 Distance from Surrounding Objects
The MP2110A takes in cooling air from the left side panel and exhausts it
from the right side panel When using two or more the MP2110A units
side-by-side, make sure that hot air exhausted from one unit is not taken
into the adjacent unit, otherwise overheating may occur.
WARNING
Do not insert any metal object like, such as tweezers or a
screwdriver, into vents on the side panels. Failure to do so
can cause electric shock.
