System Products 213
© 2020, ATEÏS. All rights reserved.
Environmental
o Operating temperature = -5ºC ~ 55ºC (23ºF ~ 131ºF)
o Storage temperature = -40ºC ~ 70ºC (-40ºF ~ 158ºF)
o Relative humidity = 15% to 90%
o Air pressure = 600 to 1100 h Pa
3.6.2 Audio Cards
3.6.2.1 Analog Audio I/O Cards
Analog audio cards are available for local inputs or outputs in blocks of 4 or in a 2 in/2 out
configuration. Highly adjustable for sensitivity and output power. An outstanding design with the
maximized flexibility by providing with true 48V phantom power for each card.
Input Audio Board:
4 Channels of analog audio inputs
Euro-block low-voltage disconnectable connectors
0, 12, 24, 40, 54dB sensitivity levels
Signal, RTO, overload indicators
-60 to +20dB faber range for level
-50 to +20dB overload threshold
Mute and bypass signal control
Volume display for each channel
Output Audio Board:
4 Channels of analog audio inputs
Euro-block low-voltage disconnectable connectors
Signal, overload indicators
-60 to +20dB faber range for level
-20 to +20dB overload threshold
Mute and bypass signal control
Volume display for each channel
3.6.2.2 Digital Audio I/O Cards
The digital audio I/O cards allow you to go all the way to digitize, present with the maximum sound
quality and transmission distance on IDA8 platform. Digital cards enhance a higher capacity of input
& output configuration with up to 8 channels in and 8 channels out on a single card.
AES/EBU-Mono Input/Output, Stereo Input/Output, Duplex Stereo
o Mono Input/Output: 4 channels audio input and 4 channels
output of digital audio
o Stereo Input/Output: 2 Channels audio input (2 x 2) and 2
channels output of digital audio (2 x 2)
o Duplex Stereo (2 CH for each channel): 4 channels audio
input (1,2 CH) and 2 channels outputs of digital audio (3,4
CH)
RTO / Overload / Signal Indicators
-20 to + 20 dB for overload threshold
-60 to + 20 dB faber range of level
