Ateis IDA8C User Manual

IDA8 Global-Net User Manual498
© 2020, ATEÏS. All rights reserved.
Current
-
0.5
ADC
Contact Output Relay
Contact Output
Contact Form
Maximum
Unit
Carry Current
1.0
ADC
Maximum Voltage
100
VDC
Electrical Life
1 x 10^8 (Ref 10VDC, 10mA)
-
Mechanical
Dimensions(W x H x D):
436mm (W) x 88mm (H) x 289mm (L)
Weight:
5Kg
Colour:
RAL7016
Operating Temperature:
0°C ~ 40°C
9.1.3 IDA8SL
Electrical
Item
Voltage
Current Consumption
Comment
AC Input
115V~230V
1.6A@100V,
0.7A@240V
Frequency:50Hz~60Hz
DC Input
18V~30V, Typical 24V
2A
-
DC Output
18V~30V, Typical 24V
0.5A
-
AC Maximum Consumption: 48W
Amplifier Zone Outputs
Maximum level: 14 dB
Output Impedance: 50 Ohm
Bandwidth: ±1dB@ 20Hz ~ 20kHz
THD+N (Total Harmonic Distortion plus Noise)
Sensitivity
Minimum
Maximum
Unit
Frequency
0dBu
-
0.04
%
20~20kHz@+4dBu
-12dBu
-
0.06
%
20~20kHz@-2dBu
-24dBu
-
0.06
%
20~20kHz@-14dBu
-40dBu
-
0.06
%
20~20kHz@-30dBu
-54dBu
-
0.06
%
20~20kHz@-44dBu
EIN (Equivalent Input Noise)
Sensitivity
Minimum
Maximum
Unit
Frequency
0dBu
-
-81
dBu
20~20kHz@150Ω
