Ateis IDA8C User Manual

IDA8 Global-Net User Manual510
© 2020, ATEÏS. All rights reserved.
50 Hz
SPA2120
Idle: 12VA
Full Power: 290VA
*Idle: Measured with
10 Volt surveillance
tone on the output
SPA2240
Idle: 11VA
Full Power: 550VA
DC Input
19-30 VDC
SPA2060
Idle: 0.16A
Full Power: 2.1A
**Per ch. @ 24 VDC
*Alarm cycle + 10 V
pilot-tone @ 48 VDC
SPA2120
Idle: 0.16A
Full Power: 4.05A
SPA2240
Idle: 0.21A
Full Power: 7.79A
Audio Characteristics
Frequency response:
±3dB@40Hz ~ 20KHz
Distortion at nominal power:
<1% (@ 1 kHz) @ -10dB of rated output)
SNR (Signal-to-noise ratio):
86dB@ 1 kHz at full power
Inputs/Outputs:
Power output: 100 V
Main line input: 770 mV
Input impedance: 20K Ohm
Mechanical
Dimensions (W x H x D):
SPA2060, SPA2120 = 425mm (W) x 305mm(D) x 88mm(H)
SPA2240 = 425mm (W) x 420mm(D) x 88mm(H)
Weight:
SPA2060 = 10.6 Kg (23.3 lbs)
SPA2120 = 12.3 Kg (27.1 lbs)
SPA2240 = 18.5 Kg (40.8 lbs)
Colour:
RAL7016
Environmental
Operating temperature:
-5ºC ~ 55ºC (23 ºF ~ 131 ºF)
Storage temperature:
-40 ºC ~ 70 ºC (-40 ºF ~ 158 ºF)
Relative humidity:
15% to 90%.
9.3.2 BPA
Electrical
Mains Power Supply AC Input:
230 VAC ±10%, 50/60 Hz
Power consumption:
Total mains-power consumption @ 230
VAC
Idle: Measured with 10 Volt surveillance
tone on the output.
Standby - idle - full load (per channel)
BPA-2060: 2.5VA - 140VA
BPA-2120: 2.5VA - 11VA - 295VA
BPA-2240: 2.5VA - 11VA - 550VA
BPA-2480: 2.5VA - 13VA - 1000VA
BPA-1000: 3.0VA - 15VA - 1000VA
Fuse rating:
BPA-2060: 2.5A @ 110 V, 1.25A @ 250 V
BPA-2120: 5 A @ 110 V, 2.5 A @ 250 V
BPA-2240: 8 A @ 110 V, 5 A @ 250 V
BPA-2480: 16 A @ 110 V, 7 A @ 250 V
BPA-1000: 18 A @ 110 V, 9 A @ 250 V
Battery Power supply 48 VDC Input:
48 - 53 VDC
Power consumption:
Alarm cycle + 10 V pilot-tones @ 48 VDC
Standby - idle - full load (per channel)
BPA-2060: 0.09 A - 2.0A
