Ateis IDA8C User Manual

Technical Data 511
© 2020, ATEÏS. All rights reserved.
Battery Power supply 48 VDC Input:
48 - 53 VDC
BPA-2120: 0.09 A - 0.16A - 4.07 A
BPA-2240: 0.09 A - 0.23A - 8.13 A
BPA-2480: 0.09 A - 0.23A - 13 A
BPA-1000: 0.12 A - 32 A
Inputs/Outputs
Input
Power inputs:
US type: 115V
EU type: 230V
Line inputs:
2 x (one per channel) for BPA-2XXX units
Connector:
3-pin XLR and 3-pin phoenix (electronically
balanced)
Frequency response:
+/-3 dB @ 50 Hz and 18 kHz
SNR (Signal-to-noise ratio):
86 dB @ 1 kHz at full power
THD (Total harmonic distortion):
< = 1 % @ 1 kHz
Sensitivity:
0.775V @ 10K Balanced
Input range:
-6 dBV to 6 dBV / 770 mV
Input impedance:
22k ohm
Output
Power outputs:
(US type: 70V, 35V, 8 Ω)
(UL type: 100V, 50V, 8 Ω)
US type:
BPA-2120:
o 120W x 2 CH,RMS (EN54-16/ UL60065)
o 60W x 2 CH,RMS (UL2572/UL1711)
BPA-2240:
o 240W x 2 CH,RMS (EN54-16/ UL60065)
o 120W x 2 CH,RMS (UL2572/UL1711)
BPA-2480:
o 480W x 2 CH,RMS (EN54-16/ UL60065)
o 240W x 2 CH,RMS (UL2572/UL1711)
BPA-1000:
o 1000W x x 1 CH, RMS (EN54-16/ UL60065)
o 500W x 1 CH,RMS (UL2572/UL1711)
EU type:
BPA-2120: 120W x 2 CH,RMS
BPA-2240: 240W x 2 CH,RMS
BPA-2480: 480W x 2 CH,RMS
BPA-1000: 1000W x x 1 CH, RMS
Frequency response:
20 Hz to 20 kHz @ -3 dB
SNR (Signal-to-noise ratio):
> 90 dB (no pilot tone) @ 20 Hz to 20 kHz
Distortion:
< 1 % (@ 1 kHz) @ -10dB of rated output
Crosstalk:
< 80 dB at nominal load for 1 kHz
Loudspeakers Outputs
BPA-2060:
Rated load resistance: 166.7 ohm (100 V); 41.6 ohm
(50 V)
Rated load capacitance: 31 nF (100V); 125 nF (50V)
Rated output power: 60W (1 min. at 40°C)(per CH)
BPA-2120:
Rated load resistance: 83 ohm (100V); 20 ohm (50V)
Rated load capacitance: 60 nF (100V); 250 nF (50V)
Rated output power: 120W (1 min. at 40°C)(per CH)

Ateis IDA8C Specifications

General

Brand	Ateis
Model	IDA8C
Category	Security System
Language	English
