Ateis IDA8C User Manual

IDA8 Global-Net User Manual522
© 2020, ATEÏS. All rights reserved.
9.5.9 URGP32I/URGP16I16O
Electrical
Item
Voltage
Current Consumption
Comment
DC Input
24VDC
30mA
-
Evacuation Inputs (Contact Mode)
Bias Voltage
Item
Minimum
Maximum
Unit
Voltage
-
5
VDC
Monitoring resistor: 4.7k Ohm
Evacuation Inputs (Voltage Mode)
On Voltage
Item
Minimum
Maximum
Unit
Voltage
18
72
VDC
Mechanical
Dimensions (W x L x H):
140mm x 75mm x 44mm
Weight:
0.48 Kg
Maximum Cable Length:
RS485: 600m on Category 5 cable
RS232: 15m
Operating temperature:
0ºC ~ 55ºC
9.5.10 CD-TOUCH
Electrical
Item
Voltage
Current Consumption
Comment
DC Input
18V~26V, Typical 24V
250mA
Microphone
Microphone level:
6dBu
Output Impedance:
100Ohm
THD:
@ 1kHz < 0.5%.
Bandwidth:
@ -3dB = 50Hz ~ 20kHz
Noise Gate Threshold:
-84dBu ~ -24dBu
Max Output Level:
-54dBu ~ 6dBu
Attack Time:
8ms
Release Time:
100ms
Front Panel Loudspeaker
Impedance:
4Ohm
Maximum Power:
@ 1kHz = 1W
THD:
@ 1kHz < 0.5%
Bandwidth:
@ -3dB = 50Hz ~ 20kHz.
Mechanical
Dimensions ( W x H x D):
400mm x 210mm x 130mm
Weight:
0.45 Kg
Color:
RAL7035
Screen:
Diagonal: 5"/ Resolution: 800 x 480
Maximum Cable Length:
100m on CAT5 cable
Operating temperature:
0ºC ~ 55ºC
