DSP Components 441
© 2020, ATEÏS. All rights reserved.
Now click on the [TC Transmit]
component to enter the telephone
number. After entering the numbers,
click [Dial] button to dial, then you
can hear the audio source from the
[Input A] component.
Before calling via DTMF code, please
follow the instruction of paging method.
Dial = #00X
o # = start
o = end
Example:
o If you would like to paging to Code
[2], then dial #002
Cancel the call = #000
Example:
o If you would like to cancel the
paging, then enter #000
o The paging function will be
canceled right way after finishing
dialing.
Redial:
When dialing the wrong code, simply redial the
correct code again after the wrong code.
Example:
If you dial the Code [3] to the wrong Code [2], you
only need to redial the correct code again (2) after the
wrong one. The situation might be shown as
#002#003 See the picture below,
The numbers during the paging will also be listed on
the [History] of [TC Receive] component window for
displaying the entered numbers, in additions, if the
code you dial has been set as the EVAC, the EVAC
signal on front panel of your machine such as IDA8C
processor will also light up.
6.26 VoIP
6.26.1 VoIP
Allow the device such as PPM-IT5, IP phone, Terra-K etc. to call via LAN/WAN. G.711, G.722, L16
and MP3 format can be supported by IDA8. The communication protocol via SIP protocol or Voxnet
format.
The [VOIP Receive] component will occupied with 1 x message channels, please refer to
Message Limitation chapter.
