IDA8 Global-Net User Manual378
© 2020, ATEÏS. All rights reserved.
Control Window
Element Description
Bypass/Mute: Disable/mute the audio channel.
Sensitivity: Set the input gain of the channel to the preamplifier.
Phantom Power: Apply 48 VDC phantom power to the channel
input for use with condenser mics.
RTO: An input channel 'Routed To Output(s)'.
Overload: Light up if the signal of an input channel is bigger than
Overload Thd.
Volume: The VU-Meter shows the channel of RMS level.
Signal: Light up if the audio signal presents above -30 dB from the
chosen 'Sensitivity'.
Level: The signal output level of channel.
Overload Thd.: A threshold value to determine the signal of channel
is overloaded or not.
6.9.2 Mono Input
Used for the AES/EBU input, it's very similar to the analog Input component except without
Sensitivity and Phantom Power values.
