Fuse Rating: 3.15A
Zone Boards
Zone Board 1: The following I/Os belong to zone board1 in IDA8C: speaker zone output
ch1~ch4, backup amplifier1, amplifier zone output ch1 ~ ch4.
Zone Board 2: The following I/Os are belong to zone board2 in IDA8C: speaker zone output
ch5~ch8, backup amplifier2, amplifier zone output ch5 ~ ch8.
3.1.1.3 Peripherals
The following table list the peripherals supported by IDA8C.
Device
Connection
Max. Num
Function
Fireman
MIC
Fireman
MIC
Input
1
Paging where operator is close to the IDA8C.
PPM AS
PDC
32
Remote console with paging ability.
PSS AS
PDC
1
Remote console for Paging and Event Triggering(Element
Control, Master/Sub Preset Control).
URC-150AS
PDC
32
Remote console for Master/Sub Preset Controlling and
Element Controlling.
URGP32I
PDC
1
Evacuation Input extension.
URGP16I16
O
PDC
1
Evacuation Input & output extension
DNM
PDC
16
Auto noise gain for audio signals
DNM
Ethernet
Ethernet
16
Ethernet type of auto noise gain for audio signals
ANM
Analog
Audio
1
Detect Background Noise
PPM-IT5
Ethernet
1 (Active
Over Eth.)
Paging, Element Control and Master/Sub Preset Control.
URC-
200AS
Ethernet
Eth. Limit
Parameters Control and Master/Sub Preset Control.
CD8
PDC
1
Wall mounted cabinet remote paging console with 8 buttons/
zones.
CD16
PDC
1
Wall mounted cabinet remote paging console with 16 buttons/
zones.
CD Touch
PDC
1
Wall mounted cabinet remote paging console with touch
screen and Fireman Microphone.
PCP
PDC
32
Wall mounted cabinet remote paging console with telephone
styled microphone.
CDPM
PDC
1
Wall mounted cabinet remote paging console with 24 buttons/
zones and 2 extra selectable microphone sources.
PSC
PDC
32
A grouped console is comprised of a pad with a monitoring
speaker, a pad with a gooseneck and 8 buttons/zones, and
two pads with 8 buttons/zones.
DialPad
PDC
1
A remote dialer for making telephone calls via IDA8's
telephone hardware.
Wireless
Transceiver
PDC
1
An RF transceiver to communication between DialPad and
IDA8, DialPad can work without a physical connection.
Max. Number: The max. number of peripherals through per PDC port by using a Junction Box. For
example: On the PDC port, you can connect 32 PPM AS through junction boxes and are able to
assign IDs in sequence for each unit in Ateis Studio.
When connecting to both Fireman Mic and other remote units, the priority status of Fireman Mic
shall be higher than any other microphone remote units lining to PDC port.
If a large number of remote units is required, simply add more slave units for the master unit.
