Ateis IDA8C User Manual

Technical Data 519
© 2020, ATEÏS. All rights reserved.
Dimensions(L x W x H):
100mm x 67mm x 30mm
STATUS LED:
Green
ø 3mm
Display the status of RF
RS485 Protocol:
RJ45 @Maximum Distance 500M{between system unit and
DialPad
24 VDC@ 30 mA maximum
RS232 connection:
DB9 @Maximum Distance 12M(between system unit and
DialPad Receiver
DC POWER connection:
DC-JACK@ 24V
24 VDC@ 30 mA maximum
Weight:
0.1 kg (0.2 lbs)
Colour:
RAL7016
Environmental
Operating temperature:
0ºC ~ 40ºC
9.5.3 DNM-485/DNM-ENET
Electrical & Connector
Power supply:
POE input:
EURO block input:
20VDC power supply (if no POE available)
Conform IEEE 802.3af
18~30 VDC, 250mA
Ethernet port:
CAT-5 cable
RS485 port:
5.08 mm EURO block (4Pin)
Include 24 VDC power:
18~30 VDC
Include RS485 of baud rate:
38400 bps @600M
Microphone:
Omnidirectional
Microphone
RS485 or Ethernet interface including POE (Power On Ethernet)
Built in Electronic Condenser microphone(omnidirectional)
Microphone input (1kHz):
-40 du
Maximum Cable Length:
600M on category 5 cable
Audio Characteristics
Sensitivity range
(60~130dBA), ±5 dBA
THD:
<0.2%
Equivalent:
-80 dBu 50~16 kHz@600Ω
THD+N @ dBu:
0.2% 50~16 kHz
Frequency response:
10 + 1 dBu 50~16 kHz@0 dBu, sample rate= 48 k
Sampling rate:
48 kHz only 1 selection
*The di erence between 1kHz and the frequency of maximum value
Mechanical & Environmental
Dimensions:
Hexagonal cylinder: 100mm(Φ) x 130mm(H)
Weight:
0.13 Kg
Operating temperature:
0ºC ~ 55ºC
Storage temperature:
-40° to +80° C
9.5.4 PPM-AS
Electrical
Item
Voltage
Current Consumption
Comment
