Ateis IDA8C User Manual

Technical Data 523
© 2020, ATEÏS. All rights reserved.
9.5.11 CD8/CD16
Electrical
Item
Voltage
Current Consumption
DC Input
18V~26V, Typical 24V
CD8: 120mA/ CD16: 150mA
Microphone
Microphone level:
6dBu
Output Impedance:
100Ohm
THD:
@ 1kHz < 1%
Bandwidth:
@ -3dB = 50Hz ~ 20kHz
Noise Gate Threshold:
-84dBu ~ -24dBu
Max Output Level:
-54dBu ~ 6dBu
Attack Time:
8ms
Release Time:
100ms
Front Panel Loudspeaker
Impedance:
8Ohm
Maximum Power:
@ 1kHz = 1W
THD:
@ 1kHz < 1%
Bandwidth:
@ -3dB = 100Hz ~ 18kHz
Mechanical
Dimensions (W x H x D):
CD8: 320mm x 190mm x 130mm
CD16: 350mm x 250mm x 130mm
Weight:
CD8: 3.6Kg /CD16: 4.7kg
Color:
RAL7016
Screen:
Diagonal: 5"/ Resolution: 800 x 480
Maximum Cable Length:
100m (control and power on the same cable)
900m (when power line connects to junction box)
Operating temperature:
0ºC ~ 55ºC
9.5.12 SHM
Microphone
Bandwidth:
@ -3dB = 300Hz ~ 6kHz
Impedance
500ohm
Sensitivity
-72dB
Mechanical
Dimensions (W x L x H):
62mm x 45mm x 102mm
Weight:
0.15kg
9.5.13 CDPM
Electrical
Item
Voltage
Current Consumption
Comment
DC Input
18V~26V, Typical 24V
200mA
-
Microphone
Microphone level:
6dBu
Output Impedance:
100Ohm
THD:
@ 1kHz < 0.1%
Bandwidth:
@ -3dB = 50Hz ~ 20kHz
Front Panel Loudspeaker
Impedance:
8Ohm
Maximum Power:
@ 1kHz = 1W
