System Configuration 279
© 2020, ATEÏS. All rights reserved.
The properties of files need to be followed by the standard format as below in order to be read
by the system.
Size: 144 x 80
Format: 24bit color bmp
Name: lamp01_d.bmp (when deselected the button)
2. Run the Ateis Studio software, tick [ Auto Search] to search the PSS, and select the IDA8
processor and click [Remote Picture Store] on Device Management to open its control window.
3. A pop-up control window will be displayed. The system devices (IDA8 processor, PSS console)
will be listed on the left side.
Tick [Auto Search] checkbox to search the PSS. If there are multiple PSS consoles you wish
to change their figure files, tick [Multi Selected] checkbox and select multiple devices.
4. After connecting to the remote, click the device(s) users intend to store pictures into it/them.
To Next Page
