Application Examples 527
© 2020, ATEÏS. All rights reserved.
Step 4: Click [...] Paging Events
button to open the front panel setup
window.
Step 5: Click "Singular" tab, then
click [Add] button to configure a
singular event.
Step 6: Click [...] Show button to
select the certain paging zones.
Under the "Name", users are free to
modify the name of the event.
Step 7: Click [...] button to open the
zone selection window.
Step 8: Select the zones(Z1, Z2,Z5
and Z6 for example) and close all the
windows to finish the paging zone
selection.
Step 9: Go back to Device window,
right click on the device and choose
"Front Panel Settings"
To Next Page
