THE I SERIES STANDARD CONTROL BOX V4.3
Communication Interface
The back of control box provides Ethernet interface, Modbus-RTU, USB interface, I/O and, as shown
below.
Figure 8.32 communication interface
Applications:
 Ethernet interface can be used for remoting access and control.
 USB interface can be used to update, import and export project.
 Modbus-RTU is used for external communication
USER I/O
Ethernet interface
USB interface
Modbus RTU
USB interface
