AUBO i5 - Orientation Control

©2015-2018 AUBO.All rights reserved.
Page 91
TEACH PENDANT USER INTERFACE V4.3
example, Euler angles).
 The drop-down menu provides whether the target is flange focus (default) or end-effector.
 Users can add new option to the drop-down menu by the TCP Setting- Tool coordinate system settings
Orientation Control
Figure 10.12 Orientation Control (base)
Figure 10.13 Orientation Control (end)
