AUBO i5 - F PAYLOAD

©2015-2018 AUBO.All rights reserved.
VII
APPENDIX V4.3
F PAYLOAD
Payload of wrist has shown above, in which d-axis represent the center of gravity offset which is the
distance between end-effector flange focus and tool focus.
1. The load conditions should within the range shown in the figure.
2. The payload shown in figure represent maximum load capacity. Shall not overload in
any case.
3. Overload may cause damage to the machine's internal parts
