Setting decimal place
This function is used to set the decimal place. The decimal place is related to the ow
rate range.
Default setting
Same as the setting ow rate range or DECIMAL PLACE:2
Setting range
DECIMAL PLACE (Single range): 0 to 4
DECIMAL PLACE (Dual or Normal/Reverse range): 0 to 4
Step
Screen
Procedure
(English) (Japanese)
1
DECIMAL PLACE
0
&
0
&
Enter ADVANCED MODE (see
page 4-23). Use the
or
key to cycle through the screens
until DECIMAL PLACE
appears.
2
DECIMAL PLACE
1
&
1
&
Touch the key to move the
cursor to the number. Use the
or key to set the desired
number.
3
DECIMAL PLACE
1
&
1
&
Touch the key to move the
cursor to back to “&”.
4
Touch the MODE key to return
to the MEASURING MODE
and save the data.
