Azbil Corporation Using the display panel
Model MGG10C/14C - MagneW FLEX+/PLUS+ Converter 4-17
Flow counter - Resetting
This function resets the current totalized value and saves it to memory. (The default
value for the counter is 000000000 at power-up.)
Step
Screen
Procedure
(English) (Japanese)
1
CNT-RESET READY
Enter BASIC SETUP MODE
(see page 4-11). (The rst
screen in this mode is always the
TAG screen.)
Use the
or key to cycle
through the screens until the
CNT-RESET screen appears.
2
CNT-RESET READY
Touch the key once to move
the cursor to READY.
3
Touch the key to select
READY and reset the counter.
READY changes to ON as the
counter resets and then changes
back to READY when it’s done.
4
CNT-RESET ON
Touch the key until the
cursor is back at the mode
indicator.Touch the MODE
key and hold for three seconds
to return to MEASUREMENT
MODE to save the new value.
To Next Page
