Azbil Corporation Using the display panel
Model MGG10C/14C - MagneW FLEX+/PLUS+ Converter 4-27
Relations for setting function FXXXX
Introduction
The range, built-in counter, contact input, and contact output functions can be set
using the combinations shown in the table below. For example, when “Single range”
and “Addition with preset” are selected, there are three contact input choices (X, 1,
and 2) and three contact output choices.
1-contact input and 1-contact output (DI/DO)
Range function
Built-in counter
function
Contact input function Contact output function
0: Single range A: Addition X: Not activated X: Not activated
1: Alarm output
4: Self-check result output
5: Empty detection function
6: High/low limit alarm
1: External 0% lock X: Not activated
1: Alarm output
4: Self-check result output
5: Empty detection function
6: High/low limit alarm
2: External auto zeroing X: Not activated
1: Alarm output
4: Self-check result output
5: Empty detection function
6: High/low limit alarm
4: Counter reset X: Not activated
1: Alarm output
4: Self-check result output
5: Empty detection function
6: High/low limit alarm
B: Addition with
preset
X: Not activated 3: Preset output
1: External 0% lock 3: Preset output
2: External auto zeroing 3: Preset output
1: Automatic switching
dual range function
A: Addition X: Not activated 2: Range switching output
1: External 0% lock 2: Range switching output
2: External auto zeroing 2: Range switching output
4: Counter reset 2: Range switching output
2: External switching
dual range
A: Addition 3: External range
switching
X: Not activated
1: Alarm output
2: Range switching output
4: Self-check result output
5: Empty detection function
6: High/low limit alarm
B: Addition with
preset
3: External range
switching
3: Preset output
3: Normal/reverse
automatic switching
range
A: Addition X: Not activated 2: Range switching output
1: External 0% lock 2: Range switching output
2: External auto zeroing 2: Range switching output
4: Counter reset 2: Range switching output
C: Normal/reverse
totalization
X: Not activated 2: Range switching output
1: External 0% lock 2: Range switching output
2: External auto zeroing 2: Range switching output
4: Counter reset 2: Range switching output
