Introduction Azbil Corporation
1-2 Model MGG10C/14C - MagneW FLEX+/PLUS+ Converter
P
ulse output
Co
ntact input/output
A
C power supply
Analog output/
Digital output
Flow signal input
Converter
Detector
Dedicated cable
Excitation output
Fluid
Figure 1-2 Remote System
